68.19. How to use state detection of IP interfaces

Enter into the Abilis control-program or open the configuration file with the Console configurator and type the following commands.

s p ip-2 state-detect:pingSet the state detecion of ip-2 resource to PING
s p ip-2 p-dst1:62.94.0.1 p-dst2:62.94.0.2Set the external servers to ping.
s p ip-2 p-gw:192.168.2.254Set the gateway to use for ping
save confSave the configuration

On a working Abilis, an initialization of the ip resource is required (init res:ip-2).
